ATV212H075N4
The Schneider ATV212H075N4 is a 0.75kW Altivar 212 industrial variable frequency drive designed for precise motor control and energy efficiency. It runs on a 480V three phase supply with sensorless vector control, a built in C3 EMC filter, and a graphic display terminal for easy programming. Modbus and CANopen communication, an integrated PID controller, and energy saving functions make it ideal for HVAC, pumps, and fans. Rated IP20 with a UL Type 1 enclosure option and a wide operating temperature range. Reach out to Aswan Electric for a fast quote and availability across the Emirates.
Schneider ATV212H075N4 Variable Frequency Drive 0.75kW 480V 3-Phase | Altivar 212 Industrial VFD | Sensorless Vector Control | Built-In EMC Filter C3 | Graphic Display Terminal | Modbus/CANopen Communication | PID Controller Integrated | Energy Saving Functions | IP20 Protection | UL Type 1 Enclosure Available | Multi-Standard Certified
Technical Specifications
| Specification | Details |
|---|---|
| Power | 0.75kW |
| Input/Output | 480V 3-phase |
| Control | Sensorless vector |
| EMC | Built-in C3 filter |
| Display | Graphic terminal |
| Communication | Modbus/CANopen |
| Functions | PID, energy saving |
| Protection | IP20 |
| Enclosure | Type 1 available |
| Standards | UL/CSA/CE |
| Temp | -25 to 70°C |
