EZ9F56420
Residential Buildings, Commercial Complexes, Office Buildings, Retail Stores, Hotels, Hospitals, Schools, Apartment Buildings, Villas, Consumer Units, Distribution Boards, Final Circuit Protection, Lighting Circuits, Power Circuits, Socket Outlets, Air Conditioning, Water Heaters, Electric Ovens, Washing Machines, General Purpose Circuits
Schneider Electric EZ9F56420 Easy9 MCB | 4 Poles 20A Rated Current | Type C Curve | 6kA / 6000A Breaking Capacity | 400V AC | Easy9 Series Budget-Friendly MCB | Cost-Effective Circuit Protection | Residential Commercial Applications | DIN Rail Mount 18mm Pitch | BS EN 60898-1 IEC 60947-2 Standards | Conventional Busbar System | Tool-Free Installation | Compact Design Space-Saving | Tunnel Terminal Connections | IP20 Protection Degree | Short Circuit Overload Protection | Modern Consumer Unit Compatible | Easy Installation Maintenance | Thermal Magnetic Protection | Instantaneous Trip | Manual Reset | ON-OFF Indication | Cable Protection | Motor Protection Compatible
Technical Specifications
| Specification | Details |
|---|---|
| Part Number | EZ9F56420 |
| Brand | Schneider Electric |
| Series | Easy9 |
| Product Type | MCB |
| Poles | 4 Poles (4P) |
| Rated Current In | 20A |
| Tripping Curve | Type C Curve |
| Breaking Capacity Icn/Icu | 6kA / 6000A |
| Rated Voltage | 400V AC |
| Standards | BS EN 60898-1, IEC 60947-2 |
| Mounting | DIN rail 35mm |
| Pitch | 18mm (2 modules per pole) |
| Protection | IP20 |
| Terminal | Tunnel type 1-35mm² |
| Operating Temp | -25°C to +70°C |
| Mechanical Life | 20,000 operations |
| Electrical Life | 10,000 operations |
| Frequency | 50/60Hz |
