EZC250H3200
The Schneider Electric EZC250H3200 is an EasyPact EZC250H molded case circuit breaker rated at 200A in a 3-pole design, with a TMD thermal-magnetic trip unit for overload and short-circuit protection. It offers a higher breaking capacity (Icu) of 36kA at 415V AC for more demanding installations. The TMD trip unit provides fixed overload and instantaneous protection, with operation up to 550V AC or 250V DC. Its larger EZC250 frame handles higher currents in a compact footprint, with positive contact indication and IP40/IP54 rotary-handle options. Compliant with IEC 60947 and UL 508 plus marine certifications, it suits industrial duty. Ideal for three-phase feeder and distribution protection in industrial plants and commercial buildings.
Buy the Schneider EZC250H3200 from Aswan Electric today. Message us on WhatsApp or send an enquiry for competitive UAE pricing.
Schneider Electric EZC250H3200 Molded Case Circuit Breaker | 3 Poles 200A Rated Current | 36kA Breaking Capacity | EasyPact Series MCCB | Thermal Magnetic Trip Unit TMD | Fixed Settings Protection | DIN Rail Panel Mount | IP40 IP54 Protection | IEC 60947-1 IEC 60947-2 Standards | Industrial Commercial Buildings | Power Distribution Motor Control | Overload Short Circuit Protection | Cost-Effective Reliable Performance | Compact Design Space-Saving | Complete Range Auxiliaries Available
Technical Specifications
| Specification | Details |
|---|---|
| Part Number | EZC250H3200 |
| Brand | Schneider Electric |
| Series | EasyPact EZC250H |
| Poles | 3 Poles |
| Rated Current In | 200A |
| Breaking Capacity Icu | 36kA at 415V AC |
| Trip Unit | TMD (Thermal-Magnetic with fixed settings) |
| Standards | IEC 60947-1, IEC 60947-2 |
| Voltage | Up to 690V AC |
| Protection | IP40 standard, IP54 optional |
| Mounting | DIN rail, Panel |
| Features | Compact design, Cost-effective, Reliable protection, Complete accessories range |
| Applications | Small to medium buildings, Standard industrial |
