EZC250N3125
The Schneider Electric EZC250N3125 is an EasyPact EZC250N molded case circuit breaker rated at 125A in a 3-pole design, with a TMD thermal-magnetic trip unit for overload and short-circuit protection. It offers a breaking capacity (Icu) of 25kA at 415V AC, delivering dependable, economical performance for three-phase distribution. The TMD trip unit provides fixed overload and instantaneous protection, with operation up to 690V AC or 250V DC. Its larger EZC250 frame handles higher currents in a compact footprint, with positive contact indication and IP40/IP54 rotary-handle options. Compliant with IEC 60947 and UL 508 plus marine certifications, it suits industrial duty. Ideal for three-phase feeder and distribution protection in industrial plants and commercial buildings.
Buy the Schneider EZC250N3125 from Aswan Electric today. Message us on WhatsApp or send an enquiry for competitive UAE pricing.
Schneider Electric EZC250N3125 Molded Case Circuit Breaker | 3 Poles 25kA Breaking Capacity | EasyPact Series MCCB | Thermal Magnetic Trip Unit TMD | Fixed Settings Protection | DIN Rail Panel Mount | IP40 IP54 Protection | IEC 60947-1 IEC 60947-2 Standards | Industrial Commercial Buildings | Power Distribution Motor Control | Overload Short Circuit Protection | Cost-Effective Reliable Performance | Compact Design Space-Saving | Complete Range Auxiliaries Available
Technical Specifications
| Specification | Details |
|---|---|
| Part Number | EZC250N3125 |
| Brand | Schneider Electric |
| Series | EasyPact EZC250N |
| Poles | 3 Poles |
| Breaking Capacity Icu | 25kA at 415V AC |
| Trip Unit | TMD (Thermal-Magnetic with fixed settings) |
| Standards | IEC 60947-1, IEC 60947-2 |
| Voltage | Up to 690V AC |
| Protection | IP40 standard, IP54 optional |
| Mounting | DIN rail, Panel |
| Features | Compact design, Cost-effective, Reliable protection, Complete accessories range |
| Applications | Small to medium buildings, Standard industrial |
