EZC250H3225
The Schneider Electric EZC250H3225 is an EasyPact EZC250H molded case circuit breaker rated at 225A in a 3-pole design, with a TMD thermal-magnetic trip unit for overload and short-circuit protection. It delivers a higher breaking capacity (Icu) of 36kA at 415V AC for more demanding installations. The TMD trip unit provides fixed overload and instantaneous protection, with operation up to 550V AC or 250V DC. Its larger EZC250 frame handles higher currents in a compact footprint, with positive contact indication and IP40/IP54 rotary-handle options. Compliant with IEC 60947 and UL 508 plus marine certifications, it suits industrial duty. Ideal for three-phase feeder and distribution protection in industrial plants and commercial buildings.
Order the Schneider EZC250H3225 from Aswan Electric now. WhatsApp us or enquire online for the best pricing across Sharjah and the UAE.
Schneider Electric EZC250H3225 Molded Case Circuit Breaker | 3 Poles 36kA Breaking Capacity | EasyPact Series MCCB | Thermal Magnetic Trip Unit TMD | Fixed Settings Protection | DIN Rail Panel Mount | IP40 IP54 Protection | IEC 60947-1 IEC 60947-2 Standards | Industrial Commercial Buildings | Power Distribution Motor Control | Overload Short Circuit Protection | Cost-Effective Reliable Performance | Compact Design Space-Saving | Complete Range Auxiliaries Available
Technical Specifications
| Specification | Details |
|---|---|
| Part Number | EZC250H3225 |
| Brand | Schneider Electric |
| Series | EasyPact EZC250H |
| Poles | 3 Poles |
| Breaking Capacity Icu | 36kA at 415V AC |
| Trip Unit | TMD (Thermal-Magnetic with fixed settings) |
| Standards | IEC 60947-1, IEC 60947-2 |
| Voltage | Up to 690V AC |
| Protection | IP40 standard, IP54 optional |
| Mounting | DIN rail, Panel |
| Features | Compact design, Cost-effective, Reliable protection, Complete accessories range |
| Applications | Small to medium buildings, Standard industrial |
